5Pin IP67 Waterproof Circular Connectors , M25 Waterproof Power
Cable Connectors
Description:
- 5Pin male plug female plug
- TUV,UL,CUL,CE approval
- Panl mount connectors: for PCB, soldering
- circular outdoor power cable connectors
- waterproof cable connector ip67
- Cable assembly supported
- industrial Electrical Plug
- Any quantity is welcome
M25 waterproof round electrical connectors is the perfect solution to make your own waterproof connection
cables easily. soldering is required and installation just takes a
few minutes.
| Operation Parameters |
| Voltage Rating | 600VAC max |
| Current Rating | 30A max |
| Min Wire Size OD | 6.5mm ~ 10mm |
| Max Wire Size OD | 10.5mm ~ 18mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 6.0mm2 |
| Technical Parameters |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Once assembled, the M25 waterproof ac power plug is easy to plug and play while keeping the elements and water out
of splices and junctions. To disconnect, just unscrew the main body
and pull apart the two ends.The M25 Waterproof conector has
multiple waterproofing levels, consisting of o-rings, waterproof
sealant, and flexible end seals designed to tighten and close when
screwed together.
Widely Usage Applicaiton of Waterproof Panel Mount Connector
- Communications Application
- Solar System
- Electric power equipment
- Outdoor and indoor led lighting
- Signal connection
- AC electrical power
FAQ
1. Q: What type waterproof connector do you have?
A: We have 17series type connector,and make more than 3000types
waterproof connector cable.Most of our connector is customized.We
foucs on LED Waterproof connector,Assembly waterproof
connector,Over-mold waterproof connector,T waterproof connector,Y
customized waterproof connector.
2.Q:Is the sample avaliable?
A: Yes, but you need to pay the samples if you wanna more types
samples, and it does not include freight. And we can refund the
corresponding samples fee if you place a batch of the orders in the
future.
3.Q: Can you assured the quality?
A: Yes, we’ve gained the CE, RoHS, ip65-ip68, UL certification. And
we’ve have strict QC team, all products will be tested before
delivery.
4.Q: What’s the terms of payment?
A: We can accept T/T, LC, Paypal and Western Union
5.Q: What’s the delivery time?
A: It depends on the quantity, as usual it will takes 3-5 for small
quantity.
